Specification
Memory : 64bit Read only memory (10HEX serial number)
Frequency : 125KHz- Dimensions: CR80 85.60 x 53.98mm
Thickness : 0.84mm
Material : PVC, PET
Card Surface : Matte/ gloss finish
Housing : Lamination
Working Frequency : 125KHz
Reading Distance : 5cm typically
Data storage time : 10 years
Feature
- 64 bit memory array laser programmable
- Several options of data rate and coding available
- On chip resonance capacitor
- On chip supply buffer capacitor
- On chip voltage limiter
- Full wave rectifier on chip
- Large modulation depth due to a low impedance
modulation device
- Operating frequency 100 - 150 kHz
- Very small chip size convenient for implantation
- Very low power consumption
Application
- Logistics automation
- Anticounterfeiting
- Access control
- Industrial transponde
